借款用途与介绍/Brief Introduction：

该线由线条式挤出机螺杆洗瓶烘干箱箱二合一机、服用液灌装设备设备分娩线轧盖机二台pc单机手机游戏成分，有擦拭、常温、干燥高压蒸汽高压蒸汽灭菌和灌装设备设备分娩线封口处三大作业区，全程可协作分娩，也可pc单机手机游戏便用。可达成淋水、彩超波擦拭、冲水、冲气、烘干箱箱高压蒸汽高压蒸汽灭菌、加热、灌装设备设备分娩线、理盖、戴盖、轧盖等生产工序。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

特质/Characteristic：

分为多普勒彩超波清洁工作及气水更迭擦拭、远红外高温环境杀菌、双头灌装设备与粘口等技木。整线对接手动有效控制。操作步骤简简单单便，保持了机械合二为一化。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

技艺主要参数/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
选用品种 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	65Kw(这其中平常事业36Kw)(including normal working 36 kw)
丝机总重量machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
