不同的用途与详细介绍/Brief Introduction：

本工作线是和30ML以内口服方式液的装罐加工线产品工作，由供瓶机、滚桶洗瓶机、平行线式装罐加工线产品轧（旋）盖机、开式标贴纸机等产品分为，可全半自动完工理瓶、洗瓶、装罐加工线产品、上盖、旋（轧）盖、标贴纸等程序。核心用做医药集团、产品、化工厂的的几种夜体物料清单的装罐加工线产品协同工作。本工作线全适合GMP符合要求。This production line is suitable for more than 30 ml of oral liquid filling production, by for bottle filling machine, roller bottle washing machine, straight-line rolling (spin) cover machine, vertical labeling machine and other equipment, can finish automatically unscramble bottle, bottle washing, filling and cover, cover and label (pad). Mainly used in pharmaceutical, food, chemical industry production of all kinds of liquid filling material of the linkage of. This production line in full compliance with GMP requirements.

优点和缺点 /Characteristic：

◆外型的材料为304不透钢，灌装线前半部采316L不透钢，符合要求GMP要求。Outer material is 304 stainless steel,and the material of filling part is 316L stainless steel, it complies with GMP regulation ◆可适应环境多品种制造。can be situable for several bottle specs.◆启用安全稳定，吵音小，灌装设备精确度高 。Stable running,low noise,precise filling.◆破瓶率低，原料优秀率高，水耗少。low bottle breakage ratio,high qualified product ratio,low energy consumption.◆整件研发线可单机手游抑制和连锁店抑制。The whole line can single machine control or interlock control.

新技术指标/Main Technical Parameters：

可用于规格型号Filling Volume	30-150ML
分装头数Productivity	中速4头             ൲; 高速收费站8头 4 at low speed            💃; high speed 8
产量工作能力	低速度30-50瓶/分     高速度70-100瓶/分 30-50bottles/min  70-100bottles/min
装灌准确度Filling Precision	≤±1%
旋盖率Capping Rate	≥99%
主机电源Power Supply	220V/50Hz
电功率Power Supply	2.5kw
生产制造线总长Dimension	7500*1000*1700MM
